Semi-auto Solar Module Laminator

  Parameters



Model

Laminating Size

(©O)

Dimension

(m)

Weight

(T)

Power

(KW)

Vacuum Pump

BSL2222OC

2. 2  m¡Á2. 2  m

2.44¡Á2.9¡Á1.3

5

Max. Power:48

Working Power: 30-36

2X-70

Technical Parameters

       Power Supply:             AC380V 3 Phases 5 Lines

       Compressed Air Pressure:     0.6¡«0.8MPa

       Compressed Air Flux:         ¡Ý0.4M3/min

       Height of Vacuum Cavity:     25mm

Temperature Uniformity:     ¡À1.5¡æ

Temperature Accuracy:        ¡À1.5¡æ

Temperature Range:          Room Temperature to 180¡æ

Laminating Time:            2¡«4min (Without Solidifying)

The Max .Vacuum:           £¼100Pa within 90s
